Infineon introduces a new CoolSET System in Package in a compact design for highly efficient power delivery up to 60 W for a wide input voltage range
A compact, fully integrated system power controller for highly efficient power delivery of up to 60 W at universal input voltage range of 85 – 305 V AC.
www.infineon.com
Housed in a small SMD package, the high-voltage MOSFET with low R DS(ON) eliminates the need for an external heat sink, reducing system size and complexity. The CoolSET SiP supports zero-voltage switching (ZVS) flyback operation, which enables low switching losses and low EMI signature, while also enhancing system reliability and robustness. This makes it an ideal solution for applications such as major home appliances and AI servers. In addition, the controller makes it easier for developers to meet stringent energy standards, supporting future-proof power solutions for modern designs.
The CoolSET SiP integrates a 950 V startup-cell, an 800 V avalanche rugged CoolMOS™ P7 SJ MOSFET, a ZVS primary flyback controller, a secondary-side synchronous rectification (SR) controller, and reinforced isolated communication enabled by Infineon’s proprietary CT Link technology. This high level of integration supports the development of more sophisticated end products by significantly reducing the number of discrete components, lowering the bill of materials, and minimizing PCB space requirements. A comprehensive set of advanced protection features simplifies system integration and allows designers more flexibility to optimize their solutions and enhance the overall user experience.
